'59 PAF
'59 PAF - Image 2

’59 PAF

The vocal late-’50s PAF.
Rich mids and a smooth, controlled top end.

Built to a defined late-’50s tonal window.
Each set measured and logged before shipping.
Hookup Wire

30-Day Right Pickup or Return It

The Vocal Late-’50s Voice

Richer mids. Smoother top end.

The thickest and most vocal point in the range.

Why the ’59?

The most mid-forward expression in the Olemy range.

Added weight through the mids and a smoother, rounder top end. Chords remain full and harmonically rich, with a low end that stays controlled. Under gain, the treble response remains composed.

Both coils follow late-’50s Leesona 102 winding patterns with no coil offset. The more uniform structure slightly lowers the resonant peak and increases distributed capacitance, shaping a thicker midrange and smoother treble character.

The result is a more expressive late-’50s voice that retains clarity and control as you play.

If you’re after the sweeter, more vocal side of a late-’50s PAF, this is it.

Tonal Profile

High End
Smooth, sweet and singing.
Midrange
Thick, harmonically rich and vocal.
Low End
Firm and balanced.
Feel
Slightly softer attack with a controlled, singing sustain.

Typical Readings

PositionDC ResistanceInductanceCapacitance
Bridge8.3 kΩ5.04 H3.81 nF
Neck7.5 kΩ4.00 H4.9 nF

Measured at 1 kHz

How it’s built

  • Screw and slug coils patterned on the Leesona 102
  • No coil offset for a smoother top end response
  • 42 AWG plain-enamel wire
  • Butyrate bobbins
  • Low-carbon steel screws and slugs
  • Pure nickel-silver baseplates and covers
  • Maple spacer and brass bobbin screws
  • UK sandcast Alnico II magnets

Each set is wound within defined electrical tolerances to hit a consistent tonal window.

The Richest Voice

The ' 59 sits at the thickest end of the Olemy range. Vocal, smooth and harmonically rich, with a sweet top end that sings under gain.
